FEMP are the series of bag filter with reverse jet cleaning to handle medium airflow.

FEMP filters are provided with a plenum chamber, creating an inertial dust separation for heavier particles allowing longer life of the nag filters.

Reverse jet cleaning by differential pressure gauge ensures a long life of filtering media

The filters are designed for handling with a forklift and equipped with lifting hooks, for a quick and easy installation.

Technical Sheet

Standard Version Specifications:

Filtering surface from 19 to 116 m²
Reverse jet cleaning with differential pressure gauge
Collection bin 200 L
Maximum vacuum 3000 Pa
Maximum temperature 80°C

Accessories:

Several filter media
Fan
Control panel or/with inverter
Ladder and walkway
Bin balanced system
Rotary valve
Fire protection stystem

Materials and finish:

Galvanized metal sheet
Stainlesssteel steel
Painted
